PRP: 50 kW / 62.5 kVA
Standby: 55 kW / 68.75 kVA
Engine: WP4D66E200
Back to List
50kW Prime Power | Robust & Efficient Power for Public Facilities, Agriculture, and Small Industry
Engine: Weichai WP4D66E200 4-Cylinder
Output: 50kW Prime / 55kW Standby
Runtime: 24 Hours @ 75% Load
Certifications: Global Standard Compliance (ISO, CE, SONCAP, etc.)
The JT-50KW is a reliable, medium-mini industrial generator powered by the mature Weichai WP4D66E200 engine. Positioned specifically for schools, rural hospitals, and agricultural processing bases, this unit bridges the gap between small mini-generators and large-scale industrial units. It combines high load-bearing capacity with ultra-low fuel consumption, providing a stable, 24-hour continuous power supply for public infrastructure and budget-sensitive projects in emerging markets. Perfectly sized for public welfare projects. It handles the mixed-load requirements of schools and rural clinics (lighting, pumps, HVAC, and office gear) without the idle waste of larger units, providing an efficient "all-in-one" power solution. Unlike over-stressed small engines, the Weichai WP4 large-displacement block ensures superior heat dissipation and stability. Its 340 N·m torque handles long-term alternating loads effortlessly, preventing the power-drop issues common in smaller generators. With an 180L fuel tank, this unit covers a full 24-hour cycle at 75% load. It is the ultimate choice for remote villages where fuel logistics are challenging, ensuring continuous power for critical services without constant supervision. With consumption as low as 194-202 g/kW·h, the JT-50KW significantly lowers operational overhead. For public facilities with fixed annual budgets, this efficiency directly translates into savings that can be reinvested into your core project. Noise levels are capped at 64-66 dB(A), meeting stringent environmental standards for hospitals and schools. You can deploy it confidently in sensitive zones without risking noise complaints or disruptions to learning and medical care. Featuring ATS compatibility and intelligent fault diagnosis, the unit handles power switching and monitoring independently. It is the perfect low-maintenance solution for locations where professional electrical staff are not available on-site. Factory-direct pricing, customized configurations (including trailer or silent canopy options), and full global support. Response guaranteed within 24 hours.Product Overview
Technical Specifications
Category Specification Model JT‑50KW Prime Power 50 kW / 62.5 kVA Standby Power 55 kW / 68.75 kVA Voltage 400/230 V Rated Current 90 A Frequency 50 Hz Engine Model Genuine Weichai WP4D66E200, 4‑Cylinder In‑Line Turbocharged Displacement 4.5 L Bore × Stroke 102 mm × 138 mm Compression Ratio 18:1 Cycle Type 4‑Cycle Diesel Engine Rated Speed 1500 RPM Peak Torque @1500RPM 340 N·m Cooling System Water‑Cooled Engine Oil Capacity 10 L Start Motor Voltage 24V DC Alternator Brand & Type Stamford/Marathon, Brushless, Self‑exciting, H‑Class Insulation, 3‑Phase Phase & Connection 3‑Phase 4‑Wire Power Factor 0.8 (lagging) Insulation Class Class H Protection Grade IP21 Total Harmonic Distortion (THD) <5% Fuel Consumption (100% Full Load) 194‑202 g/kW·h Fuel Tank Capacity 180 L / ≈24‑hr @ 75% Load Maintenance Interval 500 Working Hours Noise Level 64‑66 dB(A) @ 1 Meter Max Operating Altitude ≤ 1000 m Max Parallel Units Up to 6 Units (IEC 8528‑5) ATS Compatibility Yes Transport Dimensions 3400 × 1600 × 1900 mm Overall Weight 1.6 t Certifications ISO9001 · CE · SONCAP · PVoC · NRCS · SIRIM · SNI · TISI Lead Time 40‑45 Working Days + 40‑50 Days Ocean Freight Payment Term 30% Advance, 70% Before Shipment Core Advantages
1. Optimized "Golden" 50kW Power
2. Large-Displacement Reliability
3. 24-Hour Continuous Runtime
4. Industry-Leading Fuel Economy
5. Campus-Friendly Silent Operation
6. Automatic & Unattended Ready
