PRP: 160 kW / 200 kVA
Standby: 176 kW / 220 kVA
Engine: NTA855-GA
Back to List
JT-160KW Cummins Industrial Generator
The JT-160KW Cummins Industrial Generator sets a reliable benchmark for mid-range industrial power generation, built on the authentic and proven Cummins NTA855-GA engine platform. Engineered to withstand rigorous and harsh operating conditions, this 160kW prime power unit delivers stable, continuous power for construction projects, small-scale mining operations, industrial facilities, and telecom standby power systems.
Equipped with a large 320L fuel tank and generating a peak torque of 1,630 N·m, the unit ensures strong power reserve and excellent heavy-load startup performance. Featuring a 500-hour extended maintenance cycle, intelligent LCD diagnostic system, and full international certification compliance, the JT-160KW offers global contractors a high-reliability, low total cost of ownership (TCO) power solution for long-term prime and standby power applications. Backed by 24/7 global technical support, it delivers consistent performance wherever your projects run.
Powered by a genuine 6-cylinder turbocharged Cummins NTA855-GA engine with 18.9L large displacement, this generator adopts fully factory-calibrated power parameters. Different from ordinary entry-level assembled generator sets, the original Cummins platform provides standardized torque output, stable fuel efficiency, and transparent maintenance data. It guarantees consistent durability, compatibility, and operational stability for long-hour industrial continuous operation.
Delivering 1,630 N·m peak torque at 1500 RPM, the JT-160KW achieves a 12.4% torque upgrade compared with traditional legacy models. The outstanding torque reserve enables reliable startup and stable operation under heavy industrial loads, performing excellently even in high-temperature, high-load, and unstable working environments. It effectively avoids startup failure and voltage fluctuation caused by sudden load changes on construction and mining sites.
Matched with HLF160 brushless alternator featuring H-class insulation and IP21 protection grade, the unit is professionally optimized for harsh construction and mining scenarios. The premium insulation and sealed housing effectively prevent winding aging, dust erosion, moisture damage, and power attenuation. It maintains stable power output in long-term dusty and vibrating working conditions, extending the service life of the whole machine.
Built-in intelligent LCD control panel supports real-time monitoring of voltage, current, frequency, temperature, running hours and other core operating data. It displays accurate DTC fault codes directly on the screen, enabling maintenance teams to quickly locate faults and execute targeted troubleshooting. This intelligent diagnosis greatly reduces unnecessary site inspections, lowers maintenance labor costs, and minimizes equipment downtime.
With an optimized fuel consumption of 206–214 g/kW·h under 100% full load, the JT-160KW realizes significant energy-saving advantages over older-generation generator sets. Combined with a 500-hour long maintenance interval, it greatly reduces fuel consumption, replacement frequency of wearing parts, and overall operational expenses. For long-term prime power users, the unit brings continuous and measurable cost savings, achieving high efficiency and low TCO.
Item | Specification |
|---|---|
Prime Power | 160 kW / 200 kVA |
Standby Power | 176 kW / 220 kVA |
Voltage / Frequency | 400/230V · 50 Hz |
Rated Current | 288 A |
Engine Model | Cummins NTA855-GA (18.9L, 6-Cylinder Turbocharged) |
Peak Torque | 1,630 N·m @ 1500 RPM |
Alternator Type | HLF160 Brushless, H-Class Insulation |
Fuel Consumption (100% Load) | 206–214 g/kW·h |
Maintenance Interval | 500 Working Hours |
Overall Dimension (L×W×H) | 4000 × 1600 × 2100 mm |
Gross Weight | 4.2 Tons |
The JT-160KW Cummins industrial generator is fully certified with ISO9001, CE, SONCAP, PVoC, NRCS, SIRIM, SNI, TISI, meeting market access standards for Africa, Southeast Asia, Middle East, Europe and other global regions. It is fully qualified for engineering bidding, project installation and commercial export.
We provide 24/7 global technical assistance and after-sales support, including pre-sales project solution design, on-site installation guidance, regular maintenance guidance, and emergency fault troubleshooting. Professional global service system ensures stable operation of customer equipment all year round.
Construction site continuous power supply
Small and medium mining field power system
Telecom base station backup power
Industrial factory daily power & emergency standby power
Road, bridge and municipal engineering projects
Remote area off-grid power supply
We supply factory-direct ex-factory price, complete product datasheets, technical parameter files and full set of tender documents. Customized power solutions and packaging options are available according to project requirements. All inquiries will be responded within 24 working hours.
